KEY-116 electronic coolant
一、Product Description
KEY-116 electronic coolant; is a colorless, non-toxic, harmless insulation product, is inert liquid cold, with high dielectric constant, very low surface tension, low viscosity, volatile, and high residual stability.
It can well spread the substrate surface and various pores, play the ideal washing and wetting dissolution cleaning and have a more appropriate boiling point, which can be well used in all kinds of evaporation cycle cleaning equipment.
This product is widely used in the cleaning of various precision substrates, such as electronic precision cleaning, electronic circuit board, electronic components, precision components, various screen lens cleaning, and semiconductor, liquid crystal, hard disk making, etc., and can also be used as dehydration and drying, electronic component leakage measurement or air tightness test liquid, solvent.
二、Product characteristics
■ very low surface tension and viscosity can be well spread into various gaps, playing a good washing and wet cleaning.
■ has good electric insulation to clean and improve the operation space under charged conditions.
■ is very moderate boiling point (65℃) for various evaporation cycle cleaning equipment and cooling components during evaporation cleaning. Non-dangerous goods or not explosion, no ignition point flash point.
■ has good mobility, volatile without residue; and provides good dehydration treatment.
■ is non-toxic, harmless and nonirritating
■ environment friendly with ODP of 0 and extremely low GWP.
■ liquid can be regenerated by distillation, reducing loss and cost savings.
三、Physical performance
No ial | Features | Parameters |
1 | Appearance status: | Transparent liquid |
2 | Odor: | No less |
3 | Content: | ≧98% |
4 | Boiling point: | 65℃ |
5 | Pour point: | <-110℃ |
6 | Motion viscosity: | 0.5 cst |
7 | Steam pressure: | 142 torr |
8 | Density: | 1.68g/ml |
9 | Bispecific heat: | 0.23 cal/g ℃ |
10 | Vaporation heat: | 18 cal/g |
11 | Refraction index index; | 1.280 |
12 | Coactor of expansion: | 0.0011 cm3/cm3 ℃ |
13 | Surface tension: | 14 dyne/cm |
14 | Heat conductivity: | 0.065 W/m K |
15 | Dielectric strength: | 45K V |
16 | Dielectric constant: | 1.86 |
17 | Volume resistivity: | 1 X 1015 |
18 | Average molecular weight: | 420 amu |
19 | Water content: | <10ppm |
20 | PH value: | 7 |
21 | Flash point: | None. |
22 | ODP: | 0 |
23 | GWP: | ≤50 |
Note: 1 torr is equivalent to 1 mm mercury column pressure, an atmospheric pressure of about 100,000 Pa, and it is equivalent to 760 mm mercury column pressure. So the 1KPa is equivalent to the 7.6 torr
四、 Product characteristics
Solubility: mild
Reliability: is extremely stable
Fast drying: low boiling point, volatile completely no residue.
Regeneration: greatly reduction of industrial waste by distillation.
Penetrability: low viscosity, low surface tension, high density, high fluidity.
Safety: No flash point, it is a non-flammable liquid.
Environmental protection: no ozone consuming ODP=0 GWP= low easy through a variety of environmental standards.
五、Product use
This product is hydrofluorether compound, colorless, tasteless, non-toxic, harmless, insulation environmental protection products, can be widely used in the cleaning of various precision substrate, such as electronic precision cleaning, electronic circuit board, components, components, precision parts, various screen lens cleaning, semiconductor, LCD, hard disk, etc., can also be used as dehydration and drying, electronic component leakage or air tightness test liquid, solvent.
六、Product packaging
25KG/ barrels, 100KG/ barrels, 250KG/ barrels
七、Transportation and Storage
■ is transported by non-hazardous chemicals and non-corrosive chemicals.
■ room temperature storage.
■ Note sealing, avoiding direct sunlight and staying away from high heat.
